22,500 Litre Insulated 304 Stainless Steel Tank with Small Agitator

22,500 Litre Insulated 304 Stainless Steel Tank with Small Agitator
Location:on top
or
Call +44 (0) 1505 850 229
Description
Skirt bottom Conical top and bottom Insulation: Agitator: Dimensions: Fittings:
Specifications
Condition | Used |
Stock Number | SBS202211 |
Capacity (Litres) | 22500 |
Thickness | 100mm |
Material | rockwool |
Clad | aluminium clad |
Brand | AFG elsto |
Type | AM 802BA4 |
Kind | Propeller |
Speed | 1410/1710 rpm |
Engine power | 075 / 086 kW |
Inside diameter | 2500mm |
Outside diameter | 2750mm |
Cylindrical height | 4600mm |
Total height | 7000mm |
Skirt length | 1500mm |
Outlet height | 1000mm |
Outlet | 75mm |
Inlet | 80mm |
Breather vent | 170mm |
Type of breather vent | with bend pipe |
CIP connection | 25mm |
Type of CIP | spray ball |
Manhole | 500m |
